Features

  • Threads 1/8" - 3" pipe at 36 RPM
  • Constant and proper lubrication of dies and workpiece with through-head oiling
  • Suitable for use with RIDGID 916, 918, and 975 Roll Groover

Specifications

Nominal Pipe Capacity: 1/8" - 3" 2 1/2" - 4" with optional 141 geared threader
Bolt Capacity: 10mm - 52mm up to 30 Rc
Spindle Speed: 36 RPM
Motor: 1,700 W Universal
Switches: Reverse/Off/Forward, heavy duty, rotary-type plus integral footswitch
Chuck: Hammer-type with replacable rocker-action jaw inserts
Rear Centering Device: Cam Action
Oiling System: Adjustable flow; through-head, with an integal oil reservoir. Self priming, constant-flow, geroter pump.

Ordering Information
{{model}}
Catalog Number Model No. Description Pipe Capacity Voltage (V) Frequency (Hz) RPM Weight
in. mm lb. kg
20215 1233  50-60 Hz Universal  1/8 - 3  -  230  50 - 60  36  178  81  Buy Now
  • 11931 - Thread Cutting Oil
  • 93562 - 928 2 1/2" - 3" BSPT, Self Opening, RH
  • Die heads: Model 928 2 1/2-3''BSPT, Self-Opening, RH; Model 815A 1/8-2'' BSPT, Self-Opening, RH
  • Dies: 1/2-3/4'' BSPT Alloy, 1-2'' BSPT Alloy, 2 1/2-3'' BSPT High Speed
  • Cutter: Model 763, 1/4-3'', self-centering, with E-1032 cutter wheel
  • Reamer: Model 743, 1/4-3'', 5-Fluted
  • Key, Hex 5/32, 5/16, 1/4
20220 1233  50-60 Hz Universal  1/8 - 3  -  115  50 - 60  36  178  81  Buy Now
  • 11931 - Thread Cutting Oil
  • Die heads: Model 928 2 1/2-3''BSPT, Self-Opening, RH; Model 815A 1/8-2'' BSPT, Self-Opening, RH
  • Dies: 1/2-3/4'' BSPT Alloy, 1-2'' BSPT Alloy, 2 1/2-3'' BSPT High Speed
  • Cutter: Model 763, 1/4-3'', self-centering, with E-1032 cutter wheel
  • Reamer: Model 743, 1/4-3'', 5-Fluted
  • Key, Hex 5/32, 5/16, 1/4
Stands
{{model}}
Catalog Number Model No. Description Weight
lb. kg
22563 -  Steel Cabinet (200A)  42  19,30  Buy Now
92457 100A  100A Universal Leg & Tray Stand  75  34,50  Buy Now
92462 150A  150A Universal Wheel & Tray Stand  103  46,70  Buy Now
92467 200A  200A Universal Wheel & Cabinet Stand  104  47,20  Buy Now
58077 250  Folding Wheel Stand  45  21,00  Buy Now
Die Heads
{{model}}
Catalog Number Model No. Description Weight
lb. kg
45322 815A  815A 1/8" - 2" BSPT, Self-Opening, RH. Eur. RT  13  5,90  Buy Now
51377   2-1/2"-3 BSPT Receding Dies  -  -  Buy Now
54437 728  728 2 1/2"-3" NPT, Self-Opening, RH Dies  18  8,20  Buy Now
54452   2 1/2"-3" NPT, Receding, High-Speed Dies  -  -  Buy Now
93562 928  928 2 1/2" - 3" BSPT, Self Opening, RH  18  8,20  Buy Now
97045 531  531 1/4"-1"Bolt Die Head Quick-Open R.H./L.H.   7 1/2  3,40  Buy Now
97050 532  532 1-1/8"-2"Bolt Die Head Quick-Open R.H./L.H.   9  4,10  Buy Now
97065 811A  811A 1/8” – 2” NPT Die Head, Quick-Opening, RH  13  5,70  Buy Now
97070 811A  811A 1/8” - 2” BSPT Die Head, Quick-Opening, RH  12 1/2  5,70  Buy Now
97075 815A  815A 1/8" - 2" NPT Die Head, Self-Opening, RH  13  5,90  Buy Now
97080 815A  815A 1/8" - 2" BSPT Die Head, Self-Opening, RH  13  5,90  Buy Now
