Matador
Professional bench vise for the workshop.
RIDGID Peddinghaus vises reknowned for quality and durability, produced in Germany for over 100 years.
Read More
{{noResults}}
{{$index + 1}}.
{{wtbVendor.Name}}
{{wtbVendor.Distance}}
Directions: To Here - From Here
Call for Availability
{{wtbVendor.Distance}}
Directions: To Here - From Here
Call for Availability
{{wtbVendor.AddressLine1}}
{{wtbVendor.AddressLine2}}
{{wtbVendor.CityStatePostalCode}}
{{wtbVendor.CountryName}}
Tel: {{wtbVendor.Phone}}
{{wtbVendor.Website}}
{{wtbVendor.AddressLine2}}
{{wtbVendor.CityStatePostalCode}}
{{wtbVendor.CountryName}}
Tel: {{wtbVendor.Phone}}
{{wtbVendor.Website}}
({{resultCount}} results)
Features
- All forged steel construction 3 times stronger than cast iron
- Large hardened anvil
- Hardened and serrated jaws for maximum durability
- Machined and hardened sliding surfaces
- Rolled twin start Acme thread for precise operation and longevity
- Removable steel spindle nut
- Measuring scale
Support Documents
Brochure
Warranty
Ordering Information
| Catalog Number | Model No. | B (mm) | W (mm) | GL (mm) | S (mm) | axb (mm) | D1 (mm) | D2 (mm) | d (mm) | Weight | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| lb. | kg | ||||||||||
| 10803 | 100 | 100 | 125 | 270 | 36 | 65 x 70 | 120 | 90 | 11 | 13,0 | 6,0 |
| 10804 | 120 | 120 | 150 | 340 | 50 | 75 x 70 | 150 | 115 | 14 | 22,0 | 10,0 |
| 10805 | 140 | 140 | 200 | 440 | 55 | 95 x 90 | 180 | 145 | 14 | 39,7 | 18,0 |
| 10806 | 160 | 160 | 225 | 500 | 65 | 120 x 110 | 180 | 145 | 14 | 55,2 | 25,0 |
| 10807 | 180 | 180 | 225 | 500 | 65 | 120 x 110 | 180 | 145 | 14 | 57,4 | 26,0 |
